3D Printing Spherical Niobium Powder 45-106µm

产品型号:


Product Features

Spherical niobium powder is made by Radio Frequency Plasma Spheroidization atomized method, which has high purity hypoxia, high sphericity, smooth surface, no satellite, uniform particle size distribution, excellent flow performance, and high loose density and vibrational density.
Order(MOQ) : 1 pc
Payment : T/T ; L/C at sight
Product Origin : China
Shipping Port : Foshan / Guangzhou / Shenzhen
Lead Time : 1-7 days

Classification:Metal Powders

Keywords: tantalum powder, tungsten powder

Inquiry

Product details


Stardust company provide spherical niobium powder with high purity, low oxygen, high sphericity , smooth surface, no satellite spheres,  uniform particle size distribution. As the lightest refractory metal, niobium has the characteristics of high melting point, high temperature strength and high specific strength, and no radioactivity. It's the perfect thermal protection material and structural material for aerospace engines. Spherical niobium powder is suitable for laser/electron beam additive manufacturing,  hot isostatic pressing,  laser cladding, hot/cold coating and other processes.



We can not only provide relatively mature research on niobium spherical powder but also provide 3D printing services, metal spheroidization services, 3D printing machines and devices .



  • Spherical Niobium Powder Particle Size

5-25μm, 15-45μm, 15-53μm, 45-75μm, 45-105μm, 75-150μm.

(Various granularities can be customized according to customer requirements)





  •  Particle Size Distribution Graphic



  • Spherical Niobium Powder characteristics

High purity (≥99.9%), low oxygen (≤300ppm), high sphericity (≥98%), smooth surface, no satellite spheres, uniform particle size distribution, and excellent flow properties (≤15.0s/50g), And high apparent density (≥4.5g/cm³) and tap density (≥5.5g/cm³).



  • Spherical Niobium Powder Applicable Progress
  1. Laser/electron beam additive manufacturing (SLM/EBM, 3D printing)
  2. Laser direct deposition (DLD)
  3. Powder hot isostatic pressing (HIP)
  4. Metal injection molding (MIM)
  5. Powder metallurgy (PM)
  6. Laser cladding ( LC), and other processes.



  • Spherical Niobium Powder Packaging

Vacuum packaging, 1kg/bag, 2kg/bag; iron drum lined with plastic bag 25 kg/drum; special packaging is available according to user requirements.



  •  Chemical Composition
Chemical Composition
Element Value (%) Test Method Element Value (%) Test Method
Nb ≥99.95 Ta <0.002 ICP-AES
Cu <0.002 ICP-AES Al <0.002 ICP-AES
W <0.005 ICP-AES Mn <0.002 ICP-AES
Mo <0.002 ICP-AES Si <0.002 ICP-AES
Fe <0.005 ICP-AES Ni <0.002 ICP-AES
Ti <0.001 ICP-AES Cr <0.002 ICP-AES
Gas Impurities
Element Value (%) Test Standard Element Value (%) Test Standard
C 0.0048 GB/T 15076.8-2008 O 0.024 GB/T 15076.14-2008
H 0.0013 GB/T 15076.15-2008 N 0.012 GB/T 15076.13-2017
  • Physical Property
Density (g/cm3)  Hall Flow Rate (s/50g)
Apparent Density Tap Density Test Standard Value Test Standard
≥4.21 ≥5.43 GB/T 1479-1984
GB/T 5162-2006
11.5 GB/T 1482-2010



  • Appearance
