3D Printing Spherical Tantalum Powder 5-25µm
产品型号:
Product Features
Classification:Metal Powders
Keywords: tantalum powder, tungsten powder
Product details
Stardust company provide spherical chrome powder with high purity, low oxygen, high sphericity , smooth surface, no satellite spheres, bare hollow particle, uniform particle size distribution, excellent flow properties, and high bulk density and tap density.
Tantalum has excellent biocompatibility. The tantalum implant formed by 3D printing has the elastic modulus closest to human cartilage tissue, making it the most ideal orthopedic implant material.
Spherical molybdenum powder is suitable for laser/electron beam additive manufacturing, hot isostatic pressing, laser cladding, hot/cold coating and other processes.
We can not only provide relatively mature research on pure tantalum spherical powder but also provide 3D printing services, metal spheroidization services, 3D printing machines and devices .
- Spherical Tantalum Powder Particle Size
5-25μm, 15-45μm, 15-53μm, 45-75μm, 45-105μm, 75-150μm.
(Various granularities can be customized according to customer requirements)
- Particle Size Distribution Graphic
- Spherical Tantalum Powder characteristics
High purity (≥99.98%), low oxygen (≤200ppm), high sphericity (≥98%), smooth surface, no satellite spheres, uniform particle size distribution, and excellent flow properties (≤6.5s/50g), And high bulk density (≥9.5g/cm³) and tap density (≥10.5g/cm³).
- Spherical Tantalum Powder Applicable Progress
- Laser/electron beam additive manufacturing (SLM/EBM, 3D printing)
- Laser direct deposition (DLD)
- Powder hot isostatic pressing (HIP)
- Metal injection molding (MIM)
- Powder metallurgy (PM)
- Laser cladding ( LC), and other processes.
- Spherical Tantalum Powder Packaging
Vacuum packaging, 1kg/bag, 2kg/bag; iron drum lined with plastic bag 25 kg/drum; special packaging is available according to user requirements.
- Chemical Composition
Chemical Composition | |||||
Element | Value (%) | Test Method | Element | Value (%) | Test Method |
Ta | ≥99.9 | — | Ti | <0.001 | ICP-AES |
Fe | 0.002 | ICP-AES | Mo | <0.001 | ICP-AES |
Mg | <0.001 | ICP-AES | W | <0.001 | ICP-AES |
Cu | <0.001 | ICP-AES | Nb | 0.001 | ICP-AES |
Al | <0.001 | ICP-AES | Si | <0.001 | ICP-AES |
Ca | <0.001 | ICP-AES | Cr | <0.001 | ICP-AES |
Sn | <0.001 | ICP-AES | Ni | <0.001 | ICP-AES |
Mn | <0.001 | ICP-AES | |||
Gas Impurities | |||||
Element | Value (%) | Test Standard | Element | Value (%) | Test Standard |
C | 0.0015 | GB/T 15076.14-2008 | O | 0.086 | GB/T 15076.8-2008 |
H | 0.0014 | GB/T 15076.15-2008 | N | 0.0009 | GB/T 15076.13-2017 |
- Physical Property
Density (g/cm3) | Hall Flow Rate (s/50g) | |||
Apparent Density | Tap Density | Test Standard | Value | Test Standard |
9.57 | 10.21 | GB/T 1479-1984 GB/T 5162-2006 |
≤15.0 | GB/T 1482-2010 |
- Appearance
